HD90149326033 Four-Point Contact Ball Bearing shacman f2000 f3000 X3000 X5000 X6000 Hande

HD90149326033 Four-Point Contact Ball Bearing Product DescriptionI. Product Features1. Optimized core structure, adopting a detachable design of split inner ring + integral outer ring. Each steel ball theoretically forms four contact points with the raceways of the inner and outer rings, which conforms to the core design principle of four-point contact ball bearings. It can stably bear bidirectional axial loads, and at the same time can bear a certain radial load and moment load, adapting to the needs of multi-directional load working conditions.2. The raceway adopts a special Gothic arc design, which is precision ground with high surface smoothness. The standard contact angle is designed to be 35°, and the axial clearance can be independently defined without changing the fit between the raceway and the steel ball, ensuring uniform load transmission, reducing local stress concentration and lowering the risk of wear.3. The core components are made of high-purity bearing steel and undergo a strict heat treatment process, with high hardness and strong toughness. Combined with precision machining technology, they have excellent wear resistance, fatigue resistance and impact resistance, can adapt to complex working conditions such as high and low temperatures and high-speed operation, are not easy to deform or damage, and extend the service life.Equipped with an outer ring guided cage, optional brass or PEEK high-temperature resistant material, with a solid structure and smooth rotation. It can evenly separate the steel balls to avoid friction and collision between the steel balls, and at the same time improve the overall operation accuracy of the bearing, adapting to high-speed operation scenarios and reducing operation noise and heat generation.5. Detachable inner ring design: the inner ring can be installed separately from the outer ring and the steel ball cage assembly, which is convenient for the installation, disassembly and later maintenance of the equipment, greatly reducing maintenance man-hours and difficulty, adapting to on-site rapid maintenance needs. At the same time, the special chamfer design of the inner ring can improve the oil circuit and reduce deformation caused by axial clamping.6. Excellent sealing performance, which can effectively block the intrusion of dust and impurities, prevent lubricating oil leakage, and ensure the long-term stable operation of the bearing under complex working conditions with high dust and high load. Before leaving the factory, it has undergone strict precision testing, load testing and speed calibration, with strong performance consistency, no obvious noise during operation, no jamming phenomenon, extremely low failure rate, and meets the requirements of industry quality standards.7. Compact structure, the axial space occupation is significantly lower than that of double-row angular contact ball bearings, which is equivalent to the composite function of two sets of back-to-back angular contact ball bearings. It can be flexibly adapted to equipment with limited axial space without additional adjustment of the installation position, and has stronger adaptability.II. Product Specifications1. Model: HD90149326033 (corresponding to the standard specification of four-point contact ball bearing, can directly replace original accessories, and adapt to various heavy-duty and high-speed equipment)2. Bearing Type: Four-point contact ball bearing (single-row structure, split inner ring + integral outer ring design)3. Core Dimensions: Inner diameter 120mm, outer diameter 180mm, total width 28mm. The inner ring width is adapted to the overall structural design, the chamfer size is standard, and the outer ring is equipped with a 180° separation positioning groove for easy fixed installation, adapting to the needs of the corresponding equipment installation position.4. Rated Load: Basic rated dynamic load 180kN, basic rated static load 260kN. It can easily cope with bidirectional axial loads, certain radial loads and alternating loads, with stable and reliable load-bearing performance. It meets the adaptation requirement of Fa/Fr>1.27, and has the best adaptability to combined load working conditions mainly based on axial loads.5. Speed Parameters: Reference speed for grease lubrication is 2600r/min, reference speed for oil lubrication is 3600r/min (under the premise of sufficient lubrication and standard installation). The influence of centrifugal force is small during high-speed operation, and the stable four-point contact state can be maintained through preload optimization, adapting to medium and high-speed operation needs.6. Applicable Models/Scenarios: Mainly applicable to the transmission parts of heavy machinery, industrial gearboxes, locomotive drive systems, compressors, cranes and other equipment. It can also be used in scenarios with high requirements for operation accuracy such as precision machinery and robot joints, with wide adaptability and no need for additional customization.7. Material: Bearing steel (high-purity material, strengthened by heat treatment to improve hardness and toughness, meeting the needs of heavy-duty and high-speed working conditions); the cage can be optional brass or PEEK high-temperature resistant polymer material, adapting to different temperature working conditions.8. Working Temperature: The normal working temperature range is -30℃ to 200℃, and it can be extended to a higher temperature range with special materials, adapting to complex high and low temperature working conditions without performance attenuation.9. Other Parameters: Cylindrical hole design, no coating, net weight about 2.65kg, in line with the standards of the metric unit system, standard installation dimensions, can be directly interchanged with original parts. The inner hole is equipped with a plastic insert to prevent parts from falling off during transportation and handling, with strong adaptability.III. Product Advantages1. Outstanding Bidirectional Load-Bearing Performance: The unique four-point contact design can stably bear bidirectional axial loads, and at the same time take into account certain radial loads and moment loads. There is no need to pair and install two sets of single-row angular contact ball bearings, which greatly simplifies the equipment assembly process, adapts to multi-directional load working conditions, and has more advantages than traditional double-row bearings.2. Compact Structure and High Space Utilization: The single-row structure design reduces the axial space occupation by 50% compared with double-row angular contact ball bearings. It can be flexibly adapted to equipment with limited axial space without adjusting the equipment installation structure, improving the flexibility of equipment design, especially suitable for precision machinery and heavy equipment scenarios with limited space.3. High Operation Precision and Strong Stability: The raceway is precision ground, the contact angle is accurate, the steel balls are closely attached to the raceway, and the gap is precisely controlled. It runs stably without jitter or abnormal noise, and the operation noise is reduced by more than 30% compared with ordinary bearings. It can effectively improve the transmission efficiency of the equipment, reduce the wear of related components, and ensure the overall operation stability of the equipment, adapting to the needs of precision equipment sensitive to vibration and noise.4. Convenient Installation and Maintenance: The detachable inner ring design allows the installation and replacement of the bearing without disassembling the entire equipment, with high maintenance efficiency and reducing manual maintenance costs. At the same time, the special chamfer of the inner ring improves the oil circuit, facilitating lubrication and disassembly, adapting to on-site rapid maintenance needs, reducing equipment downtime and improving equipment operation efficiency.5. High Durability and Long Service Life: High-purity bearing steel material + strict heat treatment process, combined with optimized raceway design, has excellent wear resistance, fatigue resistance and impact resistance, and high fatigue limit load. The service life under transmission conditions is more than twice that of traditional bearings, which can effectively reduce the frequency of equipment shutdown and maintenance, lower the use cost and maintenance cost, and meet the needs of long-term continuous operation of heavy equipment.6. Strong Versatility and Wide Applicable Scenarios: It is not only suitable for heavy machinery, gearboxes and other heavy-duty equipment, but also can be used in precision machinery, robot joints and other scenarios with high requirements for precision and speed. The installation dimensions are standard, which can directly replace original accessories without additional customization, making procurement and replacement more convenient, reducing procurement costs and inventory pressure. At the same time, it adapts to complex working conditions such as high and low temperatures and high dust, with more comprehensive adaptability.7. Reliable Quality and Outstanding Cost-Effectiveness: Strictly following industry standards and precision manufacturing processes, each bearing has passed factory inspection, with stable performance and low failure rate. The load-bearing capacity is almost the same as that of a paired set of single-row angular contact ball bearings. At the same time, it has the advantages of compact structure and convenient maintenance, and its cost-effectiveness is far higher than that of traditional double-row bearings. It adapts to the needs of auto parts foreign trade and domestic procurement, taking into account practicality and economy.
